Ultrasonic Flow Meter TUF2000H DN15-DN6000 mm
ULTRASONICFLOWMETERTUF2000HULTRASON

Ultrasonic Flow Meter TUF2000H DN15-DN6000 mm

Merek Gopas

Ultrasonic Flow Meter TUF-2000H adalah perangkat pengukur laju aliran cairan portabel (handheld) berbasis teknologi ultrasonik menggunakan metode transit-time. Alat ini bekerja dengan mengukur selisih waktu tempuh gelombang ultrasonik yang bergerak searah dan berlawanan dengan aliran fluida, di mana

Pesan Sekarang
Deskripsi

Ultrasonic Flow Meter TUF2000H DN15-DN6000 mm (1/2 inch s/d 240 inch)
TUF - 2000H hand-held ultrasonic flowmeter using external clamp type sensor measuring liquid flow. Installation process is very simple, all Chinese man-machine interface, more easy to operate. Especially suitable for flow balance test and flow monitoring: drinking water, river water, sea water, cooling water, hot water, industrial waste water, oil, diesel oil, fuel oil, chemical liquid, etc.
Second, the handheld ultrasonic flowmeter features

Spesifikasi Teknis
  • Linearity: 0.5%
  • Repeatability: 0.2%
  • Accuracy: is better than the plus or minus 1%, velocity > 0.03 m/s
  • Response Time: 0 ~ 999 seconds, the user option
  • Velocity Range: ± 32 m/s
  • Section Size: 15 mm(0.59in) to 6000 mm(236.2in)
  • Accumulator: seven are. Negative. Net cumulative apparatus
  • Liquid type: all kinds of can conduction ultrasonic single homogeneous liquid
  • Ann all sex: setting value of the lock, change the data need to unlock
  • Display: 4 x 8 Chinese or 4 x 16 English
  • Communication interface: RS - 232 baud rate, 75-57600, at the same time compatible Fuji ultrasonic flowmeter, also should the user's requirements compatible with other products
  • Sensor: mark worthy to type TM1, while the other four choices
  • Sensor cable: standard for 5 m x 2, also can be extended to 10 m x 2
  • Power supply: 3 quarter AAA built-in Ni - H battery, every time is full of electric sustainable work 12 hours, AC100V - 240 V adapter
  • Data record: built-in data recorder can record 2000 line data
  • Manual accumulator: seven, key can start for calibration
  • Shell material: ABS
  • Physical size: 210 x 90 x 30 mm(8.27*3.54*1.2in)
  • 500 g(1.2 LBS) including battery
Aplikasi
  • Air & Pengolahan Air: Air minum, air bersih, air limbah, air keran, air laut, hingga air deionisasi untuk industri semikonduktor.
  • Cairan Industri & Kimia: Larutan asam/kimia, cairan korosif, alkohol, air gula, susu, dan cairan pada bengkel cat.
  • Minyak & Energi: Oli, minyak pelumas, minyak mentah (crude oil), bensin (gasoline), dan solar.
